Introduction

BeagleBone AI-64 like its predecessors (BeagleBone AI), is designed to address the open-source Community, early adopters, and anyone interested in a low cost 64-bit Dual Arm® Cortex®-A72 processor based Single Board Computer (SBC). It also offers access to many of the interfaces and allows for the use of add-on boards called capes, to add many different combinations of features. A user may also develop their own board or add their own circuitry.

Note

AI-64 has been equipped with a minimum set of features to allow the user to experience the power of the processor and is not intended as a full development platform as many of the features and interfaces supplied by the processor are not accessible from BeagleBone AI-64 via onboard support of some interfaces. It is not a complete product designed to do any particular function. It is a foundation for experimentation and learning how to program the processor and to access the peripherals by the creation of your own software and hardware.

BeagleBone Compatibility

The board is intended to provide functionality well beyond BeagleBone Black or BeagleBone AI, while still providing compatibility with BeagleBone Black’s expansion headers as much as possible. There are several significant differences between the three designs.

Table 9 Table: BeagleBone Compatibility

Feature

AI-64

AI

Black

SoC

TDA4VM

AM5729

AM3358

Arm CPU

Cortex-A72 (64-bit)

Cortex-A15 (32-bit)

Cortex-A8 (32-bit)

Arm cores/MHz

2x 2GHz

2x 1.5GHz

1x 1GHz

RAM

4GB

1GB

512MB

eMMC flash

16GB

16GB

4GB

Size

4” x 3.1”

3.4” x 2.1”

.4” x 2.1”

Display

miniDP + DSI

microHDMI

microHDMI

USB host (Type-A)

2x 5Gbps

1x 480Mbps

1x 480Mbps

USB dual-role

Type-C 5Gbps

Type-C 5Gbps

mini-AB 480Mbps

Ethernet

10/100/1000M

10/100/1000M

10/100M

M.2

E-key

-

-

WiFi/ Bluetooth

-

AzureWave AW‑CM256SM

-

Todo

add cape compatibility details

BeagleBone AI-64 Features and Specification

This section covers the specifications and features of the board and provides a high level description of the major components and interfaces that make up the board.

Table 10 Table: BeagleBone AI-64 Features and Specification

Feature

Processor

Texas Instruments TDA4VM

Graphics Engine

PowerVR® Series8XE GE8430

SDRAM Memory

LPDDR4 3.2GHz (4GB) Kingston Q3222PM1WDGTK-U

Onboard Flash

eMMC (16GB) Kingston EMMC16G-TB29-PZ90

PMIC

TPS65941213 and TPS65941111 PMICs regulator and one additional LDO.

Debug Support
2x 3 pin 3.3V TTL header

  1. WKUP_UART0: Wake-up domain serial port

  2. UART0: Main domain serial port

10-pin JTAG TAG-CONNECT footprint

Power Source

USB C or DC Jack (5V @ >3A)

PCB

4” x 3.1”

Indicators

1x Power & 5x User Controllable LEDs

USB-3.0 Client Port

Access to USB0 SuperSpeed dual-role mode via USB-C (no power output)

USB-3.0 Host Port

TUSB8041 4-port SuperSpeed hub 1x on USB1, 2x Type A Socket up-to 2.8A total depending on power input

Ethernet

Gigabit RJ45 link indicator speed indicator

SD/MMC Connector

microSD (1.8/3.3V)

User Input

  1. Reset Button

  2. Boot Button

  3. Power Button

Video Out

miniDP

Audio

via miniDP (stereo)

Weight

192gm (with heatsink)

Power

Refer to Main Board Power section

Board Component Locations

This section describes the key components on the board. It provides information on their location and function. Familiarize yourself with the various components on the board.

Board components

BeagleBone AI-64 board components below shows the locations of the connectors, LEDs, and switches on the PCB layout of the board.

../../../_images/components.webp

Fig. 55 BeagleBone AI-64 board components

  • DC Power is the main DC input that accepts 5V power.

  • Power Button alerts the processor to initiate the power down sequence and is used to power down the board.

  • GigaBit Ethernet is the connection to the LAN.

  • Serial Debug ports WKUP_UART0 for early boot from the management MCU and UART0 is for the main processor.

  • USB Client is a USB-C connection to a PC that can also power the board.

  • BOOT switch can be used to force a boot from the microSD card if the power is cycled on the board, removing power and reapplying the power to the board.

  • There are five green LEDs that can be used by the user.

  • Reset Button allows the user to reset the processor.

  • microSD slot is where a microSD card can be installed.

  • miniDP connector is where the display is connected to.

  • USB Host can be connected different USB interfaces such as Wi-Fi, Bluetooth, Keyboard, etc.

On bottom side we have,

  • TI TDA4VM processor.

  • 4GB LPDDR4 Dual Data Rate RAM memory.

  • Ethernet PHY physical interface to the network.

  • eMMC onboard MMC chip that holds up to 16GB of data.
